Specifications
Electrical Data
Current
- Maximum Power Current(Imp): 13.69;
- Short Circuit Current(Isc): 14.47±3%;
Wattage
580W
Voltage
- Maximum Power Voltage(Vmp): 42.37;
- Open Circuit Voltage(Voc): 51.02±3%;
Body Details
Material
- Front Glass: 3.2mm AR Coating Tempered Glass;
- Frame: Anodized Aluminium Alloy (Silver)
Capabilities
IP Rating
IP68
Working conditions
`-40°C to +85°C
Dimensions
Size
2278 x 1134 x 30 mm
Product Data
Order code
1229531
Product code
ODA580-36V-MH
Item Weight
860 kg
Additional
Release Date
20.12.2024
Brand
OSDA
Warranty
12 years product material / 25 years linear power output
Additional information
- Cell Type: 182∗91 N-Type Mono;
- No. of cells 144 (12 x 12)
TIER 1
Yes
