Specifications
General Information
Electrical Data
Current
- Max. Operating PV Input Current: 32+32+32A;
- Max. Input Short-Circuit Current: 60+60+60A;
- Rated AC Input/Output Current: 45.5/43.5V;
- Max. AC Input/Output Current: 50/47.9A;
Wattage
- Max. PV access power: 20000W;
- Max. PV input power: 16000W;
- Rated AC Input/Output Active Power: 10000W;
Phase
Single Phase
Voltage
- Max. PV Input Voltage: 500V ;
- Start-up voltage: 125V;
- PV Input Voltage Range: 125-500V;
- MPPT Voltage Range: 150-425V;
- Full Load MPPT Voltage Range: 200-425V;
- Rated PV Input Voltage: 370V;
Frequency
Rated Input/Output Grid Frequency/Range: 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
Power Factor
0.8 leading-0.8 lagging
Capabilities
IP Rating
IP65
Working conditions
-40 to +60℃
Dimensions
Size
420W x 670H x 233D
Product Data
Order code
12680
Product code
SUN-10KSG02LP1-EU-AM3
Items per box
1
Additional
Release Date
20.11.25
Warranty
10 years
Brand
Deye
