Specifications
General Information
Electrical Data
Wattage
16.07kWh
Current
- Recommended Charge Current: 140A
- Max. Charge/Discharge Current: 150A
Voltage
- Nominal Voltage: 51.2V
- Float Charge Voltage: 57.6V
- Discharge Cut-off Voltage: 43.2V
Body Details
Mount
Floor Mounting
Capabilities
IP Rating
IP20
Battery Capacity
314 Ah
Cells Chemistry
LiFePO4
On/Off cycles
>7000
Working conditions
- Charge temperature Range (°C): 0-60
- Discharge temperature Range (°C) -20 +60
- Storage Temperature Range(°C): 15-35
- Working Temperature Range(°C): 0-60
Dimensions
Size
690H x 630 x 240 mm
Product Data
Order code
12765
Product code
VT-48290
Items per box
1
Additional
Release Date
18.09.26
Brand
V-TAC
Additional information
Communication with Inverter: CAN
Warranty
10 years
