Specifications
General Information
LED Chip
SMD 2835
Electrical Data
Wattage/m
8W
Voltage
DC:24V
Technical Data
Light color
Warm White
Luminous flux/m
800 lm
Color Temperature
3000K
LED Quantity
120 LED/m.
Color Rendering Index CRI
>80
Luminous efficiency (lm/W)
100 lm/W
Beam angle
120°
Capabilities
IP Rating
IP20
Cut Points
Cut only on the given cut line between the copper dots.
Starting Time 100% ON
0.001 sec (instant on)
Color stability
<6
Working conditions
-20°C to +45°C
Dimensions
Width
3mm
Product Data
Order code
23024
Product code
VT-2835 120
Items per pack
1
Item Weight
0.02
Item Volume
0.000116
Items per box
400
EAN Code
3800170208919
Certificates & Standards
Certification
CE, EMC, ROHS
Energy efficiency class
F
Additional
Release Date
08.08.2023
Brand
V-TAC
