Description
Specifications
General Information
LED Chip
SAMSUNG Chip
Lifespan
30 000 hrs
Electrical Data
Wattage
10W
Voltage
AC: 220-240V
Frequency
50Hz
Power Factor
>0.9
Technical Data
Light color
Natural White
Color Temperature
4000K
Luminous flux (lm)
800 lm
Color Rendering Index CRI
>80
Body Details
Material
Die cast aluminum
Body Colour
White
Capabilities
Starting Time 100% ON
0.001 sec (instant on)
Color stability
<6
Luminous intensity, Cd
254.64 Cd Max.
On/Off cycles
>15000
Working conditions
Not suitable for use in extreme conditions. Normal working conditions is -20° +45°
Compatibility
Sensor Compatibility
IP Rating
IP65
IK Rating
IK05
Dimensions
Size
115 x 108 x 26 mm
Product Data
Order code
428
Product code
VT-10
Items per pack
1
Item Weight
0,3
Item Volume
0,000468
Items per box
20
EAN Code
3800157630849
Certificates & Standards
Energy efficiency class
A++
Certification
CE, EMC, ROHS
Additional
Brand
V-TAC
Warranty
5 years
Additional information
Grey glass[download id=”8184″][download id=”8186″][download id=”8189″][download id=”8191″][download id=”8193″][download id=”8195″][download id=”8197″][download id=”8199″][download id=”8201″][download id=”8203″]
